Simplified solenoid driver design using FET-technology with oversized transistors Reduced inrush current in power supply capacitors for longer power supply life Superior +5V Low Drop Out (LDO) regulation for operation at lower line voltages This board is a direct plug-in replacement for the original OEM driver board. Rottendog driver board for Bally and Williams WPC-89 and WPC-S All new (not 15+ year old) components and PCBĬAUTION: Not compatible with units with CPU/Sound board 520-5300-00 (LOTR and later)įits: Apollo 13, Austin Powers, Godzilla, Grand Prix, Harley Davidson, 2nd Edition, High Roller Casino, Independence Day, Lord of the Rings, Lost World Jurrassic Park, Lost in Space, Monopoly, Playboy, Roller Coaster Tycoon, Sharkey's Shootout, Simpsons Pinball Party, South Park, Space Jam, Star Wars Trilogy, Starship Troopers, Striker Xtreme etc.ĭRIVER BOARD (WDB089) € 420,00 (€ 420,00 excl. Identical component designations used to allow troubleshooting using original schematics (schematics included with purchase).
#Transistors pinball life full size#
Normal size fuses used to eliminate smaller full size fuses. Test points placed in one location and clearly marked to facilitate troubleshooting Bridge rectifier replaced with discrete 5A diodes, similar to WPC95 boards Lamp matrix upgraded to Williams style TIP107s Added test points and LEDs for all voltages generated on the board Also removed the adjustable potentiometer. Superior +5V Low Drop Out (LDO) regulation for operation at lower line voltages. This board is a direct plug-in replacement for the original OEM driver board, Rottendog Driver Board for Sega and Stern White Star Uses a low voltage reset to prevent the microprocessor from locking upįits: Algar, Alien Poker, Blackout, Contact, Disco Fever, Firepower, Flash, Gorgar, Hot Tip, Laser Ball, Lucky Seven, Phoenix, Pokerino, Scorpion, Stellar Wars, Time Warp, Tri Zone, World Cup.ĭRIVER BOARD (SDB004) € 420,00 (€ 420,00 excl. Uses sockets for common failure components (micro, PIAs and RAM).
#Transistors pinball life drivers#
Uses logic-level FET drivers for all solenoids and lamp controls Uses Williams WPC-like circuit design for controlled lamps (TIP107) Uses a single commercial oscillator chip for timing
Uses 6802 instead of 6800 microprocessor Comprehensive on-board diagnostics with Leon's test code via DIP switches Game ROMs are selectable via DIP switches Eliminates the need to swap out game ROMs. Eliminates the extremely problematic connector that holds the original boards together This board replaces both the MPU board and the driver board for ALL Williams System 3, 4 and 6 pinball machines.Īdvantages over the original Williams MPU and driver board Rottendog Driver & MPU Board for Williams System 3 through 6 Uses standard connectors that modders have been using for years, as well as the new *ticket style*.Supplies up to 3 amps of current safely at 12 volts and 1/2 amp at 5 volts.The power supply is fused on both the input and output side providing clean and safe accessory power. This supply is strong and safe enough to support under-cabinet lighting alongside other mods on your SPIKE pinball machine. This Pinball Life Accessory Power Supply for Stern SPIKE system machines (see compatibility list below) is used to safely supply 12vdc and 5vdc power to all of your mods. The ultimate power distribution system for Stern pinball machines using the SPIKE operating system has finally arrived!
